Products / Carpet Tile Range / Huka Falls 10
Heavy CommercialArea of use
0.3NRC acoustic
31 dBImpact sound (Lw)
45-85%Recycled content
8.7Kw/m2Critical radiant flux
15 YearWarranty
Certifications and credentials
- GREENGUARD GoldLow chemical emissions
- Green Label PlusIndoor air quality
- Smart AntimicrobialBuilt in
- Recycled ECONYL® nylonRegenerated fibre
EcoTx is our patented underlay system, applied at the manufacturing stage so its performance is built in from the start. Tiles backed with EcoTx deliver superior acoustics in both NRC and IIC.
Tiles combine freely with each other and with other carpet ranges, giving designers room to zone spaces, add pattern and soften sound.
See Huka Falls 10 in your light
Colour changes with the room. Hold a real sample against your walls, joinery and lighting before you specify.
- Free samples
- Technical data sent with your samples
- Design hubs in Auckland and Christchurch
Performance and sustainability
Range-level data. Ask us for the full technical file with your free sample.
Performance
| Area of Use | Heavy Commercial |
|---|---|
| Stability Delamination | ASTM D3936 ≥ 3.0 lbs/in ISO 11857 ≥ 26 N GB/T 26843 ≥ 26 N |
| Stability - Dimensional Stability | ISO 2551 ≤ 0.1%QB/T 2755 ≤ 0.1% |
| Stability - Tuft Bind | ASTM D1335 ≥ 8.0lbs ISO 4919 ≥ 30N QB/T 1090 ≥ 24N (QB/T 2755) |
| Wear - Castor Chair | ISO 4918 ≥ 2.4 QB/T 2755 ≤ 0.15% |
| Colour Fastness to Light | AATCC 16E ≥ 4 at 60 AFU’s ISO 105-B02 ≥ 4-5 GB/T 8427 ≥ 4-5 |
| Colour Fastness to Rubbing and Crocking | AATCC 165 ≥ 4 ISO 105-X12 ≥ 4-5 GB/T 3920 ≥ 4-5 |
| Colour Fastness to Water | AATCC 107 ≥ 4 ISO 105-E01 ≥ 4-5 GB/T 5713 ≥ 4-5 |
| Critical Radiant Flux | 8.7Kw/m2 |
| Antistatic | AATCC 134 < 3.5kV ISO 6356 ≤ 2.0 kV GB/T 18044 ≤ 2.0kV |
| Antimicrobial | Smart Antimicrobial |
General
| Acoustic - NRC | Absorption Coefficient - NRC 0.3 - T1615-4 |
|---|---|
| Acoustic - IIC | Lw = 31 dB - T1615-4 |
| Dynamic Loading | ISO 2094 < 15% Thickness loss QB/T 1091 <15% Thickness Loss |
| Static Loading | ISO 3415 < 15% Thickness loss QB/T 1092 <15% Thickness Loss |
Environmental and warranty
| Total Recycled Content | 45-85% Depending on Face yarn selected |
|---|---|
| Indoor Air Quality | Green Label Plus, GREENGUARD Gold |
| Warranty | 15 Year Standard Warranty |
